Hyundai HY100 4 inch Petrol Clean Water Pump, 20m Total Head, 7m Lift, 1250L/min Flow Rate
Hyundai HY100 4 inch Petrol Clean Water Pump, 20m Total Head, 7m Lift, 1250L/min Flow Rate
The HY100 is a petrol-powered self-priming centrifugal water pump from Hyundai. Powered by the 389cc Hyundai 4-stroke single cylinder petrol engine the HY100 delivers a max output of 13 hp.
Transferring large volumes of water fast and effortlessly the HY100 is ideal for commercial, domestic and professional pumping applications.
The HY100 is ideal for flood defence, construction work or use in industrial sectors where huge transfers of water are necessary and provides a maximum flow rate of 1250 litres per minute, allowing a rapid transfer of large pools of clean water.
This impressive pumping power is made possible due to the large 4" (100mm) inlet and outlet and is designed to be used primarily in freshwater, able of processing solid particles up to 9mm in diameter and producing a suction lift of 7m, and a total lift of 20m.
Weighing 41kg, this is a lightweight water pump that is built with transportation and storage in mind. The sturdy open frame protects the pump from knocks and bumps and also functions as a convenient carry handle.
Features:
389cc Hyundai engine: Providing impressive and reliable pumping power.
Ideal for irrigation, drainage utilities, construction, hire fleets and wash down applications
4" inlet and outlet.
Lightweight design: For easy transportation and storage.
Abrasion resistant
6.5L fuel tank: Providing a long running time for uninterrupted pumping.
Open frame: Protects the water pump from any knocks and bumps.
Comes With:
1x HY100 Petrol Trash Water Pump
1x Filter
1x Spark Plug Spanner
1x User Manual
Product Specification:
Model: HY100
Barcode: 5056275722852
Start Method: Recoil
Pump Type: Aluminium Housing
Water Type: Clean
Fuel: Petrol
Fuel Capacity (L): 6.5
Impeller Type: Cast Iron
Drive Type: Direct Drive
Engine Oil: 5W-30
Engine Oil Capacity (ml): 1.1
Max Flow Rate (L/min): 1250
Max Flow Rate (L/hr): 75000
Inlet (inches/mm): 4/100
Outlet (inches/mm): 4/100
Max Solids (mm): 9
Suction Lift (m): 7
Total Lift (m): 20
Engine Model: IC390
Engine Type Hyundai: IC390
Engine Size (cc): 389
Rated Power (kW/kVA): 8.6
Max Power (kW/kVA): 9
Maximum Power @ 3000rpm (hp/kw): 10.7/8
Maximum Power @ 3600rpm (hp/kw): 12/9
Net Installed Power @ 3000rpm (hp/kw): 10.7/8
Net Installed Power @ 3600rpm (hp/kw): 12/9
Speed (RPM): 3600
Noise Level (db): 104
Net Weight (kg): 31
Fully Assembled Dimensions (H x W x L) (mm): 480 x 420 x 450
Package Dimensions (H x W x L) (mm): 660 x 510 x 550
Fuel Type / Power Source: Petrol
Product Type: Water Pump
Due to delivery restrictions we are only able to deliver this to UK Mainland addresses. Unfortunately if your delivery address includes the Scottish Highlands, Northern Ireland & The Isle of Wight then your order will get cancelled automatically.
**images for illustrative purposes only – please refer to description and specification for full details of product**
